VOL.15 NO.2 (published in Dec-2007)

VOL.15 NO.2 (published in Dec-2007)

Current Trend and Future Prospect of WTE

Daisuke AYUKAWA*
(*Environmental Engineering Dept.1)


The use of new energy has been promoted as a means of fighting global warming, and there is growing interest in power generation from waste(WTE). In this article, we have discussed the transition of WTE and the ways of enhancing its power generation efficiency, referring to the growth of power generation, changes in facilities and steam specifications since year 2000. We have tried to estimate the extant of advancement in power generation efficiency to be gained by factors such as super-heated steam conditions, lower air ratio, lower exhaust gas temperature and use of extracted turbine steam. We have also examined the effect of pollution limit values to the power generation efficiency. We have touched on the bio-gasification + incineration as the future technology, and on the water-injected furnace as a means of power-generation enhancement. The situation in Europe has been introduced where waste incineration is construed as WTE (Waste to Energy), with comparison to our domestic waste management situation. In Europe, a power transmission efficiency of 22~26% is required. We believe this can be achieved in Japan with the improvement of WTE power generation efficiency matched with the pollution limits.

Reduction of Dioxin Emissions by Retrofitting a Munincipal Solid
Waste Incinerator and its Environmental Impact (2nd Report)

Shigehiro SHIBAKAWA*,Takahiro MASUDA**,Yasuyuki FUJITA**
and Akihiro MATSUMOTO***

(*Lake side Project,**Environmental Engineering Dept.1,
***Energy & Environment Development Dept.)


After building a continuously-operated incineration facility according to "The New Guideline for Dioxin Control 1997" next to a batch operation plant that was built roughly twenty years ago, dioxins emission from the old and the new plants and the contamination in the neighboring areas were measured. This enabled us to ascertain the reduction of environmental load by the replacement of the old plant with the new one. The dioxins emissions from the stack and its maximum concentration in the neighborhood atmosphere have been greatly reduced, resulting in the cumulative reduction of its concentration in pine needles. The simulation of atmospheric dioxins diffusion based on the dioxins emission data at the plants revealed that the simulated and measured values were nearly the same when the old facility was in operation. However, the simulated data were lower by several orders than the measured concentration when the new plant was in operation, suggesting that the effect of the new plant to it's environment cannot be accurately estimated with the parameters used for this test.

Development of Catalytic Reforming of Tar in Biomass Gasification Processes (2nd Report)

Kazuhiro SATO* and Kaoru FUJIMOTO**
(*Energy & Environmental Research Center,**The University of Kitakyushu)


Gasification of tar by catalytic steam reforming was examined in a biomass gasification processes. Various carrier and promoter for the Ni catalyst have been tested for improving resistance to coking and sulfur poisoning. An MgO-CaO carrier has produced a high coking resistance and good thermal stability, while the addition of WO3 promoter has exhibited superior resistance to sulfur poisoning. This has enabled a much more stable tar reforming activity than commercial catalysts. It has also shown a high tar-reforming performance even in gas containing sulfur that precluded the use of general catalysts.

Monitoring and Controlling System of Waste Incineration Facility using On-Line Simulation

Yoshiji MATSUDA* and Dawei LIU**
(*Electrical & Instrumentation Dept. **Energy & Environment Development Dept.)


In designing an MSW incineration furnace, thermal fluid simulation has been used for optimizing the furnace shape and the location of the secondary combustion air nozzle.

In an actual operation of the furnace, the waste feed rate and the primary combustion-air flow are controlled so that a certain level of steam generation, hence a constant combustion heating value, are maintained. This means that the furnace may not be performing under an ideal combustion condition matching the kind of waste, and the location of the burn-off point and the combustion air volume may vary even though the steam generation remains steady. This can cause CO spikes and NOx surge.

In order to solve this problem, we have broadened the application of the simulation by adding a process simulator, a combustion simulation system and a scanning device. The new system uses on-line furnace process data that enable combustion simulation in much shorter time. By the quick simulation, comparison with the ideal conditions can be made, enabling the monitoring and the optimum control of the operation to bring it close to the ideal condition.

The result of the simulation by this new system has proven satisfactory for the monitoring and controlling of the waste incineration facility.

Plant Operation Report -Fujisawa City-North Environmental Agency-(PFI at work)

Daiji SATO*,Yuji OMOTO* and Kohei BESHI*
(*Environmental Engineering Dept.)


Fujisawa City-North Environmental Agency Plant #1 is the second municipal MSW plant in which we embodied our Mass・Burn Renaissance combustion technology, and our first operating plant under PFI. Test operation began October 2006, and the plant delivery was completed on March 31, 2007. The plant has been operating satisfactorily since it launched a commercial operation on April 1, 2007. This plant was built to run for 20 years with steadfast and economical operation.

Power Generation Plant Burning Industrial Waste from Paper Recycling Process

Hiroaki HYUGA* and Hiroaki OZAKI**
(*Energy Engineering Dept.2,**Energy Engineering Dept.1)


The waste generated by the paper mills recycling cardboard has been incinerated for heat recovery, but effective treatment is difficult due to its high moisture content.

Effective use of the industrial paper waste as a biomass fuel would reduce the fossil fuel consumption in the paper plant, lowering the emission of the green house grasses.

We have built a stoker-type incineration power generating plant with the latest high-efficiency combustion technology for Rengo Ltd. in its Yashiro plant. It burns industrial paper waste while recovering the energy as steam and electricity.

The preceding article reports on the outline of the plant design, and the result of its test operation.

Outline and Start-up Operation of Demonstration Plant of Alkaline Pretreatment Hydrogen-Methane Fermentation of Shochu Distillation Lees (2nd Report)

Katsushi WADA* and Takashi KAWANO*
(*Energy and Environment Development Dept., Technical Center)


We have conducted energy recovery tests with "The verification tests for energy recovery with alkaline pretreatment-hydrogen-methane fermentation of shochu distillation leesEusing sweet potato shochu distillation lees and barley shochu distillation lees.

Under the rated operation, sweet potato shochu distillation lees generated 0.75m3-H2 and 258m3-CH4 per one ton of CODcr while barley shochu distillation lees produced 1.75m3-H2 and 238m3-CH4. The CODcr removal rate were 72% and 68% , respectively. The energy recovery rates of the fermentation part were 71% for sweet potato shochu distillation lees and 74% for barley shochu distillation lees.

Evaluation of Various Bio-substrate Fermentation Performances in Thermophilic Dry Methane Fermentation

Hong FENG*,Ken-ichi SHISHIDA*,Naoki IRIE* and Takahiro YOSHII**
(*Sewage Engineering Dept.**Energy and Environment Development Dept.)


The lab-scale experiments, in continuous and batch operations, were carried out to determine BMP (Bio-methane potential) of waste paper and waste glycerin, and to measure the ammonia nitrogen generating performance of the proteins in the fermented materials in thermophilic dry methane fermentation. The waste paper thermophilic BMP were 371~637m3N/ton-feedstock, different according to the paper variety. The waste glycerin thermophilic BMP was 1,080m3N/ton-feedstock, and methane gas production ratio from the feedstock was 90.9% on CODcr base. The CODcr/TN of feedstock seemed to affect the ammonia nitrogen generation ratio from the feedstock protein. The ammonia nitrogen generation ratio fell as CODcr/TN of feedstock increased.

Development of Waste-Sorting System Suitable for Dry Methane Fermentation

Naoki IRIE*, Daisuke IWASAKI* and Yasusuke KUBORI
(*Sewage Engineering Dept.)


In managing wastes, it is recommended to improve the total energy efficiency by directing wet, organic waste to methane fermentation while taking dry waste such as plastics to incineration. With this background, we have developed a simple system of waste separation by which materials suitable for fermentation are selectively recovered and the unsuitable materials are removed.

Separation test of MSW using simple mechanical system has proved that more than 98% of the raw waste fit for methane fermentation can be recovered by using an optimum screen diameter. It has reduces the portion of unfit materials such as plastics to less than 20% of the total waste stream.

We have confirmed that the waste thus sorted and fermented has generated 167m3 of gas (methane concentration:56%) per one ton of sorted waste.

The above result proves that we have here a waste sorting system that efficiently recovers materials suitable for methane fermentation.

Development of Methanol Synthesis Process from Wood Biomass (2nd Report)

Muneharu FUJIKAWA*, Hiroki YAMASAKI*, Hitoshi HARADA*,
Kazuhiro SATO* and Masaharu SAKAGAMI*

(*Energy & Environmental Research Center)


We have been developing a methanol synthesis process using the process gas produced by biomass gasification. A new methanol reactor has been developed that is more efficient than the conventional reactors in order to build a system that matches the small-scale, decentralized biomass processing facilities. Methanol synthesis test in bench-scale plant has confirmed that the yield of methanol has been improved thanks to the effects of methanol condensation and extraction by the local cooling inside the reactor.

As the result of methanol synthesis test from the gasification of scrap wood and pruning branch as wood biomass, we have observed both performed stable operation. We examined the test on the conditions of the air-fuel ratio (λ) 0.40~0.45 and the steam/carbon ratio(S/C) 0.55~1.15 for the optimization test of the gasification conditions. As the result, the yield of methanol in the one-pass unchanged because the CO concentrations decreased though H2/CO of the process gas increased when S/C was increased. Additionally, considering that when S/C is increased, it is necessary to increase λ for the maintenance of the temperature of the gasifier, S/C of 0.5~0.7 is realistic condition in this system.
